kubernetes 항목들이 수집되는 fluent-bit conf 설정



기본 샘플이라 생각하고 여기서 더 효율적으로 수정 반영이 가능합니다.



• 구성
  • helm chart fluent-bit -> AWS Opensearch 전송
    • Opensearch user, password 대신 IAM 권한으로 오픈서치에 연결

# fluent-bit configmap

apiVersion: v1
data:
  custom_parsers.conf: |
    [PARSER]
        Name    custom-tag
        Format  regex
        Regex   ^(?<namespace_name>[^_]+)\.(?<pod_name>[a-z0-9](?:[-a-z0-9]*[a-z0-9])?(?:\.[a-z0-9]([-a-z0-9]*[a-z0-9])?)*)\.(?<container_name>.+)\.(?<container_id>[a-z0-9]{64})

    [MULTILINE_PARSER]
        Name multiline_regex
        Type regex
        Flush_Timeout 1000
        Rule "start_state" "/^(\d+\-\d+\-\d+) (.*)/" "cont"
        Rule "cont" "/^(?!\d+\-\d+\-\d+).*/" "cont"
  fluent-bit.conf: |
    [SERVICE]
        Daemon Off
        Flush 1
        Log_Level info
        Parsers_File custom_parsers.conf
        HTTP_Server On
        HTTP_Listen 0.0.0.0
        HTTP_Port 2020
        Health_Check On

    [INPUT]
        Name tail
        Path /var/log/containers/*my-service*.log
        Exclude_Path /var/log/containers/kube-*.log,/var/log/containers/eks-*.log,/var/log/containers/*-csi-*.log,/var/log/containers/aws-*.log,/var/log/containers/argocd-*.log,/var/log/containers/metrics-*.log,/var/log/containers/fluent-*.log
        multiline.parser docker, cri
        Tag               my-service.<namespace_name>.<pod_name>.<container_name>.<container_id>

        Tag_Regex (?<pod_name>[a-z0-9](?:[-a-z0-9]*[a-z0-9])?(?:\\.[a-z0-9]([-a-z0-9]*[a-z0-9])?)*)_(?<namespace_name>[^_]+)_(?<container_name>.+)-(?<container_id>[a-z0-9]{64})\.log$
        Mem_Buf_Limit 64MB
        Skip_Long_Lines On
        Skip_Empty_Lines On
        Buffer_Chunk_Size 64KB
        Buffer_Max_Size 256KB

    [FILTER]
        Name kubernetes
        Match my-service.*
        Kube_Tag_Prefix my-service.
        Regex_Parser custom-tag
        Kube_URL https://kubernetes.default.svc:443
        Kube_CA_File /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
        Kube_Token_File /var/run/secrets/kubernetes.io/serviceaccount/token
        Keep_Log Off
        Merge_Log On
        Merge_Log_Key log
        K8S-Logging.Parser On
        K8S-Logging.Exclude On

    [FILTER]
        Name multiline
        Match my-service.*
        Multiline.Parser multiline_regex
        Multiline.key_content log
        Buffer off

    [OUTPUT]
        Name opensearch
        Match my-service.*
        Host ${OPENSEARCH_ENDPOINT}
        Port 443
        #HTTP_User ${OPENSEARCH_USER}
        #HTTP_Passwd ${OPENSEARCH_PASSWORD}
        TLS On
        AWS_Auth On
        AWS_Region ${AWS_REGION}
        Index ${INDEX_NAME}-%Y%m%d
        Type _doc
        Replace_Dots On
        Suppress_Type_Name On
kind: ConfigMap
metadata:
  annotations:
    meta.helm.sh/release-name: fluent-bit
    meta.helm.sh/release-namespace: logging
  labels:
    app.kubernetes.io/instance: fluent-bit
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: fluent-bit
    app.kubernetes.io/version: 3.0.4
    helm.sh/chart: fluent-bit-0.46.7
  name: fluent-bit
  namespace: logging





${} 로 감싸진 부분은 daemonset env 에서 넘겨줘야 합니다.

my-service 부분은 서비스 이름에 맞게 커스터마이징 할 수 있습니다.



        env:
        - name: TZ
          value: Asia/Seoul
        - name: OPENSEARCH_ENDPOINT
          value: yourdomain.com
        - name: AWS_REGION
          value: ap-northeast-2
        - name: INDEX_NAME
          value: my-service-logs







오픈 서치 (OpenSearch) 에서 확인되는 모습
